TED136125WL 3 Pole 125 Amp 480 Volt 14k

TED136125WL Bolt-on 125 Amp 3 Pole 480 Volt 14k

Specifications :

	Circuit Breaker	Type TED
	Manufacturer	GE
	Cat. Number	TED136125WL
	Also Called	TED -3125
	Maximum Voltage	480 Volt
	Amperage	125 Amps
	Poles	3 Pole Circuit
	Mounting	Bolt-on
	Model	TypeTED
	Tripping Method	Thermal Magnetic
	AIC Ratings	14k @ 480 Volt

The TED "bolt-on" circuit breaker for use on grounded 480Y/277 Vac systems. The bolt-on mounting base accessory makes the TED suitable for varied applications as a lug-lug breaker. All TED circuit breakers feature Quick-make / Quick-break mechanisms, common trip bars, and easy to spot trip indication to ensure safety and reliability. TED breakers are available in 1, 2, and 3 pole versions. 2and;3 pole versions can be ordered with auxiliary contact, shunt trip, under-voltage release, or bell alarm accessories.
